Length The total number of bits to be shifted by the BSL. The bit address must be specified to the bit level. Bit Address The location of the bit which will be added to the array. EN = enable /DN = done /ER = error /UL = unload. Control Contains the instruction bits, the Length of the array, and the bit pointer. The data is shifted left through the array, then unloaded, one bit at a time.įile The address of the bit array to be shifted.

The BSL instruction loads data into a bit array on a false-to-true rung transition, one bit at a time.

Anyone interested in how manufacturing processes are executed.

Manufacturing Operators looking to progress in their career.

Software Engineers who are seeking to learn about controlling hardware.

Electrical Technicians / Electricians looking to expand their knowledge into controls.

Electrical Engineers looking for a crash course on PLCs.What is the target audience for the class? You will have a good understanding of manufacturing systems as a whole.You will be able to create simple Human Machine Interface (HMI) screens and controlling them via a PLC.You will be comfortable creating basic ladder logic programs and troubleshoot complex existing ones.You will have a good understanding of what a PLC does, how it does it as well as what the outcomes of those actions are.The main objective of this course is to get you job-ready by the time you finish the last lecture.If that's not possible, I would advise spending some time working with an emulator and browsing through data sheets and manuals which will be presented to you in the course. You don't need any hardware or software to follow the lectures, however, it is highly recommended to get some practice before going into an interview.As some one who has administered interviews to PLC technicians, these questions are crucial in making sure that you've understood the material presented. These lessons are designed to strengthen your knowledge of PLCs and give you an edge during interviews.Īt the end of each section, you will face a quiz which will allow you to test yourself on the material you have learned before moving to the next section.

We will take a much deeper dive with hands on labs and practice sessions during which I will give you specific real world scenarios to work with and give you tips and common pitfalls. We will cover basic topics such as what a PLC is used for, how it is able to receive and process Inputs & Outputs. In this class, you will learn absolutely everything necessary to land a job as an entry level PLC technician (engineer, etc.).
